Product Details - features, specs, options, etc.
| Tapper | MT-SA-Ⅰ | |
|
|
|
〈Features〉
◎Slender design
●Synchro error compensation on tension and compression
〈Functions〉
Combination Chart
| Matching Collets | |
|---|---|
| SA412-Ⅰ | TC1022 |
| SA1022-Ⅰ | TC412 |
| SA206-Ⅰ | TC206 |
| Options |
|---|
| Model TC collets ※ Not included. Sold separately. |
| MT-SA-Ⅰ |
|
| Model |
L0 [mm] |
L1 [mm] |
C1 [mm] |
F1※ [mm] |
F2※ [mm] |
Capacity |
Weight [kg] |
List Price [JPY] |
DXF |
|---|---|---|---|---|---|---|---|---|---|
| MT2-SA206-Ⅰ | 129.5 | 97.5 | 23 | 10 | 10 | M 2～M 8 | 0.31 | 38,000 | Download |
| MT2-SA412-Ⅰ | 150.0 | 106.5 | 35 | 20 | M 3～M 12 | 0.61 | Download | ||
| MT3-SA412-Ⅰ | M 3～M 16 | 0.76 | Download | ||||||
| MT3-SA1022-Ⅰ | 210.0 | 145.0 | 50 | 30 | M 8～M 22 | 1.66 | 42,000 | Download | |
| MT4-SA1022-Ⅰ | M 8～M 27 | 1.99 | Download |
※ F1: Compression, F2: Tension
